Deepwell reservoir in 8- or 12-row format for laboratory automation
Deepwell reservoirs are designed for use in laboratory robots and automated liquid handling systems. The separated rows are aligned with 8- and 12-channel pipettes, enabling simultaneous aspiration or dispensing across all channels. This supports improved efficiency in high-throughput laboratories.
The reservoirs are manufactured from virgin polypropylene, offering high chemical resistance and an extra smooth inner surface to reduce liquid loss. The low-profile design optimises workspace usage, while the V-shaped bottom under each position ensures maximum residual recovery. The product is produced in ANSI-SBS compatible format and is suitable for storage at temperatures down to –80 °C.
Key features
- Designed for laboratory robots and liquid handling systems
- Row configuration compatible with 8- and 12-channel pipettes
- Manufactured from virgin polypropylene
- Smooth inner surface to minimise reagent loss
- Low-profile design
- Available with 8 or 12 rows
- V-bottom for maximum liquid recovery
- DNase, RNase and pyrogen free
- Complies with ANSI-SBS standards
- Suitable for storage down to –80 °C
Technical specifications
- Material: Virgin polypropylene
- Format: ANSI-SBS
- Number of rows: 8 or 12
- Storage temperature: Down to –80 °C
- Plate dimensions, 8-well version (L × W × H): 85.04 × 127.04 × 44.00 mm
